Build Data
Cylinders: 4
Discharge Line Diameter: 28mm / 1-1/8"
Model Reference Number: 4NC-20.2, 4C2397PH
Piston Cylinder Diameter: 70mm
Short Block: UPC-4NE-20-2NU
Suction Line Diameter: 42mm / 1-5/8"
Unloading Heads: 1
Performance Data
Frequency: 60hz
Horse Power: N/A
Ideal Oil Pressure At install: 1.4-3.5bar / 20-50psi
Ideal Terminal Volts At install: 208v / 230v / 460v
Oil Type: POE ISO32
Phase: 3
Purpose: N/A
Terminal Amps At Install: 73.4A(208) / 66.4A(230) / 33.2A(460)
Voltage: 208v - 230v / 440v - 480v
