Build Data
Cylinders: 6
Discharge Line Diameter: 35mm / 1-3/8"
Model Reference Number: 6J-22.2, 6B4060PL
Piston Cylinder Diameter: 65mm
Short Block: UPC-6JE-25-2NU
Suction Line Diameter: 54mm / 2-1/8"
Unloading Heads: 2
Performance Data
Frequency: 60hz
Horse Power: N/A
Ideal Oil Pressure At install: 1.4-3.5bar / 20-50psi
Ideal Terminal Volts At install: 208v / 230v / 460v
Oil Type: POE ISO32
Phase: 3
Purpose: N/A
Terminal Amps At Install: 102.6A(208) / 92.8A(230) / 46.4A(460)
Voltage: 208v - 230v / 440v - 480v
